Product Description

Supplied as an upgrade to the standard trigger head for 750ml bottles only. . The canyon unit is rated to minimum 50,000 pulls and delivers a fully adjustable spray pattern. Ideal for larger work and to avoid repetitive strain from spraying.

The CHS Industrial trigger spray is built to a very high standard and designed to be re-used.

Canyon CHS-3A, industrial professional trigger sprayer

CHS-3A

The world-renowned industrial trigger sprayer. The preferred choice for professionals who value reliability and performance.

Features

A closable twist nozzle system, allowing an adjustable spray or jet function.
A sealed venting system allowing the sprayer to be shipped filled with liquid, reducing costs.
Two types of closure are available for compatibility with a range of bottle sizes: 28/400 or 28/410
Range of accessories available with extended and flexible tubing in order to fit a wider range of containers.
Available in PCR Material.

Benefits

Customise your design with choice of colour, cap and tube

Designed to be user-friendly when using protective gloves

Leak-proof venting system allows bottles to be shipped filled with liquid

Resistant against even the most aggressive liquids

Technical info

Spray output per stroke	1.1cc + 0.2cc (water)
Spray pattern	170mm + 30mm (150mm distance)
Weight	37g
Spray angle	0o ~ 60o
Endurance	minimum 50,000 trigger pulls

Technology

Along with its robust design, the CHS-3A provides a closable twist nozzle system, allowing for an adjustable spray or jet function.  It functions by allowing the liquid to travel up the tube, past the ball valve and into the cylinder, filling the spring-loaded piston.  Once the trigger is pulled the liquid passes the second valve before exciting the nozzle via the spinner end exiting through the nozzle.
